KYORITSU 1009 Auto Range Digital Multimeter
The KYORITSU 1009 is a compact, reliable, and high-performing digital multimeter designed to meet international safety standards (IEC 61010-1, CAT III 300V). Ideal for both professionals and hobbyists, this device offers precision and ease of use for a variety of electrical measurements.
Specifications
| Measurement | Range | Accuracy |
| DC Voltage (DCV) | 400mV, 4V, 40V, 400V, 600V |
±0.6%rdg ±4dgt (depending on range)
|
| AC Voltage (ACV) | 400mV, 4V, 40V, 400V, 600V |
±1.6%rdg ±4dgt (50/60Hz)
|
| DC Current (DCA) | 400µA, 4000µA, 40mA, 400mA, 10A | ±1.0%rdg ±4dgt |
| AC Current (ACA) | 400µA, 4000µA, 40mA, 400mA, 10A |
±2.0%rdg ±4dgt (50/60Hz)
|
| Resistance (Ω) | 400Ω, 4kΩ, 40kΩ, 400kΩ, 4MΩ, 40MΩ | ±3.5%rdg ±5dgt |
| Capacitance | 40nF, 400nF, 4µF, 40µF, 100µF | ±3.5%rdg ±10dgt |
| Frequency | 5.12Hz to 10MHz | ±0.1%rdg ±5dgt |
| Diode Check | Forward Voltage Display | - |
| Continuity Check | Buzzer below ~100Ω | - |
General Specifications
|
General Specifications |
Details |
|
Safety Standards |
IEC 61010-1, CAT III 300V
|
|
Power Supply |
Two AA (R6P) batteries
|
|
Display |
LCD, maximum reading of 3999
|
|
Dimensions |
161mm x 82mm x 50mm
|
|
Weight |
Approx. 260g (with batteries)
|
|
Auto Power Off |
After ~30 minutes of inactivity
|
|
Accessories Included |
Test leads, holster, batteries, instruction manual
|
Made in: China
Warranty: 1 year
