Fluke 787 ProcessMeter, Loop Calibrator & Multimeter 1000V, 20 mA DC, True-RMS
Overview of Fluke 787 ProcessMeter
The Fluke 787 ProcessMeter is a professional-grade instrument that combines a True-RMS digital multimeter with a 4–20 mA loop calibrator in one rugged device. Designed for industrial and process control environments, the Fluke 787 ProcessMeter allows technicians to measure voltage up to 1000V while sourcing, simulating, and measuring DC current signals accurately. Its compact design and reliable performance make the Fluke 787 ProcessMeter an essential tool for calibration, troubleshooting, and maintenance of control systems.
✨ Key Features
-
Combines a loop calibrator and multimeter in one unit
-
Source, simulate, and measure 20 mA DC current loops
-
True RMS AC voltage and current measurement
-
Large, backlit display for easy visibility in low light
-
1000 V overload protection on volts, ohms, and frequency
-
Includes auto-step and auto-ramp features for mA output
-
Durable, compact, and easy to carry on-site
-
Compatible with Fluke ToolPak™ magnetic hanger (optional)
🛠️ Specification
| Current measurement | Range | 0-1 A |
| Resolution | 1 mA | |
| Accuracy | 0.2% + 2 LSD | |
| Range | 0-30 mA | |
| Resolution | 0.001 mA | |
| Accuracy | 0.05% + 2 LSD | |
| Current sourcing | Range | 0-20 mA or 4-20 mA |
| Resolution | 0.05% of span | |
| Drive Capability | 500 Ω @ 24 mA | |
| Frequency | To 19.999 kHz, 0.005% + 1 LSD | |
| Continuity | Beeps for resistance < 100 ohms | |
| Voltage measurement | Range | 0-1000 V AC or DC |
| Resolution | 0.1 mV to 1.0 V | |
| Accuracy | 0.1% Rdg + 1 LSD (VDC) | |
| Resistance measurement | To 40 MΩ, 0.2% + 1 LSD | |
| Diode test | 2.4 V shows diode voltage drop | |
| Environmental Specifications | ||
| Operating temperature | -20°C to 55°C | |
| Storage temperature | -40°C to 60°C | |
| Humidity (without condensation) | 95% up to 30°C | |
| 75% up to 40°C | ||
| 45% up to 50°C | ||
| 35% up to 55°C | ||
| Temperature coefficient | 0.05 x (specified accuracy) per °C (for temperatures < 18°C or > 28°C) | |
| Safety Specifications | ||
| Electrical safety | Designed in accordance with IEC 1010-1, ANSI/ISA S82.01-1994 and CAN/CSA C22.2 No. 1010.1-92 | |
| Overvoltage category | IEC 1010-1 CAT III | |
| Maximum voltage | 1000 V rms | |
| Mechanical and General Specifications | ||
| Size | 32 x 87 x 187 mm | |
| Weight | 369 g | |
| Batteries | Single 9 V Alkaline battery (ANSI/NEDA 1604A or IEC 6LR61) | |
| Warranty | 3 years | |
| Battery life | 50 hours typical (measurement), 12 hours typical (sourcing 12 mA) | |
| Shock and vibration | Random, 2 g, 5-500 Hz | |
| 1 meter drop test | ||
| Display current and % of span | Yes | |
| Auto step, auto ramp | Yes | |
