**TC01C is for iPhone models with USB-C port — iPhone 15 series and later. If you have an older iPhone with Lightning port, choose TC01B instead.

Features & Benefits

• 256 x 192 Pixel Resolution — Professional Image Quality
  High-resolution 256 x 192 IR detector with 12μm pixel size delivers detailed thermal images comparable to dedicated handheld thermal cameras — capturing fine temperature differences invisible to the naked eye.
• 50mK Thermal Sensitivity — Detect the Smallest Differences
  Ultra-fine 50mK (0.05°C) thermal sensitivity detects minute temperature variations — essential for identifying early-stage electrical faults, insulation issues and moisture problems before they escalate.
• Wide -20°C to 550°C Temperature Range
  Wide measurement range from -20°C to 550°C covers everything from cold storage monitoring to high-temperature industrial equipment inspection in a single pocket-sized device.
• ±2% / ±2°C Accuracy
  Reliable ±2% or ±2°C accuracy ensures consistent, trustworthy thermal readings for professional inspection and reporting.
• 25 Hz Frame Rate — Smooth Live Video
  25 Hz refresh rate delivers smooth, real-time thermal video for live monitoring and recording of moving targets or dynamic temperature changes.
• Real-Time High & Low Temperature Capture
  Automatically identifies and captures the hottest and coldest points in the frame in real time — ensuring no critical temperature anomaly is missed during scanning.
• Automatic Alarm & Image Capture
  Automatically captures images and records video when temperature exceeds user-set thresholds — enabling unmanned monitoring and ensuring critical events are always captured.
• Comprehensive Temperature Analysis
  Supports analysis of 5 spots, 5 lines and 5 areas simultaneously via the professional Fluke iSee app — providing detailed thermal mapping for complex inspection scenarios.
• Auto Time-Lapse Capture
  Automatic time-lapse mode captures sequential images over time for unattended monitoring of temperature trends and thermal changes in equipment or buildings.
• Automatic Infrared Inspection Report Generation
  Automatically generates professional infrared inspection reports from captured images — simplifying documentation, archiving and sharing with clients or colleagues.
• Real-Time Image & Video Sharing
  Share and manage thermal images and videos in real time via the Fluke iSee app — enabling fast, efficient communication and collaboration on inspection findings.
• More Than 10 Colour Palettes
  Live preview in more than 10 standard or custom colour palettes allows users to optimise image contrast and visualisation for different inspection environments and materials.
• Adjustable Emissivity
  User-adjustable emissivity settings accommodate different surface materials — improving measurement accuracy across metals, plastics, ceramics and other surfaces.
• IP56 Dust & Water Protection
  IP56-rated ingress protection (with protective cover) shields the camera from dust and powerful water jets — built for demanding industrial and field inspection environments.
• 1-Metre Drop Test Rated
  Survives a 1-metre drop — meeting Fluke's durability standards for professional field instruments.
• 22g Ultra-Lightweight Aluminium Body
  At only 22g, the TC01C is made from specially treated aluminium with a laser-etched surface — durable, premium and light enough to carry everywhere without adding bulk to your toolkit.

Applications

• Electrical panel and switchgear hotspot detection
• Motor and bearing temperature monitoring
• HVAC system and building envelope inspection
• Solar panel and photovoltaic system inspection
• Mechanical equipment preventive maintenance
• Building insulation and moisture detection
• Industrial process temperature monitoring
• Automotive and engine diagnostics

Why Choose Fluke iSee TC01C?

• Professional 256 x 192 thermal imaging in a 22g pocket device
• Native iOS integration via USB-C for iPhone 15 and later
• Wide -20°C to 550°C range for diverse applications
• 50mK ultra-fine thermal sensitivity
• IP56 dust and water protection for field use
• Auto alarm, capture and report generation
• Real-time image and video sharing via Fluke iSee app
• 10+ colour palettes for optimised visualisation
• Trusted Fluke professional instrument quality
• 2-year Fluke warranty
