KYORITSU 2010 AC/DC Digital Clamp Meter
The KYORITSU 2010 AC/DC Digital Clamp Meters are high-precision instruments designed for safe and accurate measurement of AC and DC currents. The KEW 2010 features a compact ergonomic design, clear digital display, and stable readings, ensuring reliable operation. Its portability and performance make the KYORITSU 2010 AC/DC Digital Clamp Meters ideal for electricians, maintenance technicians, and engineers performing field testing and troubleshooting.
Key Features:
- High Sensitivity: Measures small currents with resolutions of 0.1mA (AC) and 1mA (DC).
- Miniature Design: Compact and lightweight for easy handling and portability.
- Output Terminal: Connects to recorders for detailed current analysis.
- Wide Frequency Response: Operates from DC to 2kHz for versatile measurement needs.
- Safe for Low-Voltage Circuits: Designed for use on circuits below 60V AC/DC.
Specifications Table
| Function | Range | Accuracy |
|---|---|---|
| AC Current (ACA) | 200mA / 2A / 20A | ±1%rdg ±2dgt [50/60Hz] (200mA); ±1.5%rdg ±8dgt [40Hz - 2kHz] (200mA); ±1%rdg ±2dgt [50/60Hz] (2A); ±2.5%rdg ±10dgt [40Hz - 2kHz] (2/20A) |
| DC Current (DCA) | 2A / 20A | ±1%rdg ±2dgt (2A); ±1.5%rdg ±4dgt (20A) |
| Frequency Response | DC, 40Hz - 2kHz | — |
| Output | Recorder: DC200mV (against AC200mA/2/20A and DC2/20A) | — |
| Conductor Size | Ø7.5mm max. | — |
General Specifications
| Feature | Details |
|---|---|
| Power Source | 6LR61 (9V) × 1 or AC Adapter |
| Dimensions | 142 × 64 × 26mm (Main Unit); 153 × 23 × 18mm (Clamp Sensor) |
| Weight | Approx. 220g |
| Accessories Included | Carrying case (9095), 6LF22 (9V) × 1, instruction manual |
| Optional Accessories | Output cord (7256) |
Warranty: 1 Year
Made In: Japan
| Warranty period | 1 Year Warranty |
|---|---|
| Coverage | Free repair or replacement for defects in material and workmanship arising during normal use within 1 year from the date of purchase. Test leads, probes and plug leads supplied with the instrument are covered for 1 year against production defects. |
| Not covered | Fuses and batteries; normal wear of test leads and probes (cuts, burns, broken tips, worn insulation); damage from accident, dropping, overload, misuse, or use outside the instrument's rated specifications. |
| Warranty void if | The instrument has been opened, repaired or modified by a party not authorised by Kyoritsu or its Malaysian distributor. |
