SATA12508-12518 3/8" Dr. 6PT VDE Insulated Socket, 8-18mm | 9 Sizes

Product Overview

The SATA12508–12518 3/8" Dr. 6-Point VDE Insulated Socket is a precision-forged safety tool built for technicians who work on or near live electrical systems. Each socket is cold-extruded from chrome vanadium (Cr-V) steel, individually insulated, and tested by German VDE to withstand 10,000V — well above the 1000V AC/1500V DC rating it's certified for in service — in accordance with IEC/EN 60900. A chrome-plated finish under the insulation resists corrosion, and the 6-point hex opening grips fastener flats securely to reduce slipping and rounding. Sizing runs from 8mm to 18mm across nine individually numbered SKUs, all sharing the same 45mm overall length.

Important: VDE-insulated sockets are a safety-critical PPE-adjacent tool. Inspect insulation for cracks, nicks, or wear before every use, never use a socket with damaged insulation, and pair only with VDE-insulated drive tools (ratchet, extension) when working live. Insulation rating and certification apply to the tool as supplied — do not modify, grind, or re-plate.

Key Features

• VDE certified, tested to 10,000V — individually verified for insulation integrity and withstand voltage, per IEC/EN 60900
• 1000V-rated insulation — safe for use on or near live low-voltage electrical systems
• 6-point (hex) socket opening — maximum contact surface for a secure grip and reduced fastener rounding
• Cold-extruded Cr-V (chrome vanadium) steel — high strength-to-weight with excellent fatigue resistance
• Chrome-plated surface finish — corrosion resistant beneath the insulating jacket
• 3/8" square drive — pairs with SATA 3/8" VDE-insulated ratchets and extensions
• SATA lifetime warranty — backed by one of the most trusted names in professional insulated tools

Specification Table

Certified by German VDE per IEC/EN 60900. Made in China. Dimensions and weights are approximate and may vary within manufacturing tolerance.

Available Options (Variants)

Select your size from the dropdown:

Package Contents

• 1 × SATA 3/8" Dr. 6PT VDE Insulated Socket (size as selected)

Warranty Terms

Lifetime Warranty. Every SKU in this range (SATA12508, 12510–12514, 12516–12518) explicitly lists Lifetime Warranty on its individual product page — none needed the fallback exclusion clause. This SATA socket is covered against manufacturing defects in materials and workmanship when used as intended. The warranty does not cover damage from misuse, use with non-insulated or power/impact tools, cuts or abrasion to the insulating jacket, normal wear, or cosmetic wear.

Why Choose SATA?

SATA has grown into one of the fastest-growing premium-quality mechanics' hand tool brands in the world over the past two decades. Trusted by automotive technicians and industrial professionals across more than 50 countries, SATA tools are manufactured in ISO 9001–certified facilities and meet or exceed ANSI and DIN standards. In 1999, SATA became the first hand tool manufacturer in China to offer a lifetime warranty on its products — a commitment to quality and durability that professionals rely on every day. For insulated tools specifically, SATA's VDE certification and individual 10,000V testing give electricians and maintenance crews independently verified assurance the tool performs as rated, every time. As part of Apex Tool Group, SATA combines global manufacturing scale with a singular focus on performance, precision, and long-term reliability.

• ✅ VDE certified, IEC/EN 60900 compliant
• ✅ ISO 9001–certified manufacturing
• ✅ Lifetime warranty on covered products
• ✅ Trusted by professional electricians and mechanics in 50+ countries
• ✅ Precision-engineered for consistent, reliable, and safe performance
