SHERWOOD Cobalt Drill Bits for Stainless Steel 1–13mm DIN338
Tidak dapat memuatkan ketersediaan pengambilan
Overview Summary
The SHERWOOD Cobalt Drill for Stainless Steel Series is engineered for demanding drilling applications requiring strength, durability, and precision. Manufactured from 5% cobalt high speed steel (HSS-Co), these heavy-duty straight shank jobber drills are designed to withstand elevated temperatures and maintain cutting performance even under high-speed operations.
Suitable for drilling stainless steel, hardened steels, bronze, and acid-resistant materials, these drills provide extended tool life, superior corrosion resistance, and consistent accuracy. The 135° split point ensures fast penetration, reduced walking, and precise hole positioning, making them ideal for professional engineering, fabrication, and maintenance tasks.
Available in sizes from 1.00mm to 13.00mm, this range provides flexibility across multiple industrial and workshop drilling requirements.
Key Features
- Manufactured from 5% Cobalt High Speed Steel (HSS-Co)
- Designed for stainless steel and high tensile materials
- Capable of cutting materials up to 1,400 N/mm² tensile strength
- 135° split point for accurate drilling and reduced wandering
- High resistance to heat and wear
- Bronze oxide finish improves corrosion resistance
- Ground flute design enhances chip evacuation
- Longer cutting edge life reduces sharpening frequency
- Suitable for professional industrial applications
- Manufactured to DIN 338B and BS 328 standards
Typical Applications
Suitable for drilling:
- Stainless steel
- Alloy steel
- Hardened steel
- Very hard bronze
- Heat-resistant steel
- Acid-resistant steel
- General engineering materials
Multi-Variation Specification Table
| Model No | Drill Diameter | Overall Length (mm) | Flute Length (mm) |
|---|---|---|---|
| SHR0261210A | 1.00mm | 34 | 12 |
| SHR0261214C | 1.20mm | 38 | 16 |
| SHR0261216D | 1.30mm | 38 | 16 |
| SHR0261218E | 1.40mm | 40 | 18 |
| SHR0261220F | 1.50mm | 40 | 18 |
| SHR0261222G | 1.60mm | 43 | 20 |
| SHR0261224H | 1.70mm | 43 | 20 |
| SHR0261226J | 1.80mm | 46 | 22 |
| SHR0261228K | 1.90mm | 46 | 22 |
| SHR0261230L | 2.00mm | 49 | 24 |
| SHR0261232M | 2.10mm | 49 | 24 |
| SHR0261234N | 2.20mm | 53 | 27 |
| SHR0261236P | 2.30mm | 53 | 27 |
| SHR0261238Q | 2.40mm | 57 | 30 |
| SHR0261240R | 2.50mm | 57 | 30 |
| SHR0261242S | 2.60mm | 57 | 30 |
| SHR0261244T | 2.70mm | 61 | 33 |
| SHR0261246V | 2.80mm | 61 | 33 |
| SHR0261248W | 3.00mm | 61 | 33 |
| SHR0261250X | 3.10mm | 65 | 36 |
| SHR0261252Y | 3.20mm | 65 | 36 |
| SHR0261254Z | 3.30mm | 65 | 36 |
| SHR0261256A | 3.40mm | 70 | 39 |
| SHR0261258B | 3.50mm | 70 | 39 |
| SHR0261260C | 3.60mm | 70 | 39 |
| SHR0261262D | 3.70mm | 70 | 39 |
| SHR0261264E | 3.80mm | 75 | 43 |
| SHR0261266F | 3.90mm | 75 | 43 |
| SHR0261268G | 4.00mm | 75 | 43 |
| SHR0261270H | 4.10mm | 75 | 43 |
| SHR0261272J | 4.20mm | 75 | 43 |
| SHR0261274K | 4.30mm | 80 | 47 |
| SHR0261278M | 4.60mm | 80 | 47 |
| SHR0261280N | 4.70mm | 80 | 47 |
| SHR0261282P | 4.80mm | 86 | 52 |
| SHR0261284Q | 4.90mm | 86 | 52 |
| SHR0261286R | 5.00mm | 86 | 52 |
| SHR0261288S | 5.10mm | 86 | 52 |
| SHR0261290T | 5.20mm | 86 | 52 |
| SHR0261292V | 5.30mm | 86 | 52 |
| SHR0261294W | 5.50mm | 93 | 57 |
| SHR0261296X | 5.60mm | 93 | 57 |
| SHR0261298Y | 5.70mm | 93 | 57 |
| SHR0261300Z | 5.80mm | 93 | 57 |
| SHR0261302A | 6.00mm | 93 | 57 |
| SHR0261304B | 6.10mm | 101 | 63 |
| SHR0261306C | 6.20mm | 101 | 63 |
| SHR0261308D | 6.30mm | 101 | 63 |
| SHR0261310E | 6.50mm | 101 | 63 |
| SHR0261312F | 6.60mm | 101 | 63 |
| SHR0261314G | 6.70mm | 101 | 63 |
| SHR0261316H | 6.80mm | 109 | 69 |
| SHR0261318J | 7.00mm | 109 | 69 |
| SHR0261320K | 7.20mm | 109 | 69 |
| SHR0261322L | 7.50mm | 109 | 69 |
| SHR0261324M | 7.70mm | 117 | 75 |
| SHR0261326N | 8.00mm | 117 | 75 |
| SHR0261328P | 8.50mm | 117 | 75 |
| SHR0261330Q | 9.00mm | 125 | 81 |
| SHR0261332R | 9.50mm | 125 | 81 |
| SHR0261334S | 10.00mm | 133 | 87 |
| SHR0261336T | 10.20mm | 133 | 87 |
| SHR0261338V | 10.50mm | 133 | 87 |
| SHR0261340W | 11.00mm | 133 | 87 |
| SHR0261342X | 11.50mm | 142 | 94 |
| SHR0261344Y | 12.00mm | 151 | 101 |
| SHR0261346Z | 12.50mm | 151 | 101 |
| SHR0261348A | 13.00mm | 151 | 101 |
General Technical Specifications
| Attribute | Value |
|---|---|
| Brand | SHERWOOD |
| Material | Cobalt High Speed Steel (HSS-Co) |
| Cobalt Content | 5% |
| Finish | Bronze Oxide |
| Cutting Direction | Right Hand |
| Flute Type | Spiral |
| Flute Construction | Ground Flute |
| Helix Type | Normal Helix |
| Number of Flutes | 2 |
| Point Angle | 135° |
| Point Type | Split Point |
| Shank Type | Straight Shank |
| Coolant Delivery | External |
| Drill Standard | DIN 338B |
| Additional Standard | BS 328 |
| Drill Diameter Tolerance | h8 |
| Shank Diameter Tolerance | f11 |
| Web Thickness | Strengthened |
| Tensile Strength Capacity | Up to 1,400 N/mm² |
| Application | Stainless Steel & High Strength Materials |
Package Content
- 1 Piece SHERWOOD Cobalt Drill Bit
- Individual size based on selected model number
- Secure protective packaging
Warranty Term
Manufacturing Defect Warranty
SHERWOOD cobalt drills are covered against manufacturing defects. Warranty does not cover damage caused by misuse, overheating, or improper drilling techniques.
Why Choose SHERWOOD
Professional Performance You Can Trust
SHERWOOD cutting tools are engineered to deliver consistent precision, durability, and reliability. With strict adherence to international standards such as DIN 338B and BS 328, SHERWOOD tools provide dependable performance across industrial and workshop environments.
Choosing SHERWOOD means:
- Reliable industrial-grade quality
- Long tool lifespan
- Excellent heat resistance
- Trusted global manufacturing standards
- Consistent drilling accuracy
