Hitachi Bebicon Air Compressor 5hp, 8Bar, 158kg 3.7P-9.5V5A

Model: 3.7P-9.5V5A (Three Phase)
Hitachi Bebicon oil flooded 5HP, 8 Bar, three phase air compressor.

3.7 : 3750 watts (5HP)
P : Pressure Switch Type
9.5 : Maximum Pressure of 0.93MPa (9.5 Bar)
(Due to safety purpose, all the pressure is set to 8 Bar in Malaysia)
V : New V Series
5 : Frequency (50Hz)
A : Asia

Features :

• High Cooling Head - High Cooling Head with large aluminium alloy ventilated rib improves heat radiaton and air capacity.
• V-groove located between discharge and suction chamber reduces the heat transfer from discharge chamber to suction chamber and improves air capacity.
• Lead Air Valve - Lead Valve of I-shaped-stainless-steel-suction-air valve improves air capacity and improves durability against rusting.

• Heat Cut Piston Pin & Leak Cut Piston Ring - Heat Cut Piston Pin of heat-insulating material reduces heat transfer from the piston to the needle bearing and keeps bearing in relatively low temperature and improves the reliability.
• Leak Cut Piston Ring of specially shaped abutment joint reduces air leakage and improves air capacity.
• Bebicon Oil - Bebicon Oil is high performance oil and specially developed for Bebicon compressors. Please make sure to use Bebicon Oil to save power, to prevent performance degradation and to prevent accident.

Specifications :

Standard Accessories :

• Pressure Gauge
• Safety Valve
• Hose Joint
• V-Belt
• Belt Cover
• Silencer
• Stop Valve
• 1/4B Air Outlet x 1
• 3/8B Air Outlet x 1
