KYORITSU 2117R AC Digital Clamp Meter with True-RMS | KEW 2117R

Name: KYORITSU 2117R AC Digital Clamp Meter with True-RMS | KEW 2117R
Brand: KYORITSU
SKU: KE 2117R
Price: 337.00 MYR
Availability: InStock

In stock - 374 items available

SKU: KE 2117R

RM337.00 MYR

-14% ~~RM390.00 MYR~~ RM337.00 MYR

Helpful Documents

Product Brochure Download
Product Datasheet / User manual Download

Couldn't load pickup availability

Got questions?

Feel free to WhatsApp us

Ask an expert

Chat Email +6012-9725395

KEW 2117R AC Clamp Meter

Get the Kyoritsu KEW 2117R Digital Clamp Meter, the top affordable multimeter on Shopee. True RMS, 1000A AC current, AC/DC voltage, and resistance measurements with a user-friendly design.

Video:

Key Features:

True RMS Measurements: Accurate current readings with auto-ranging for 60A, 600A, and 1000A.
Ergonomic Design: Over-molded body allows convenient one-hand operation.
Large Display: Easy-to-read screen with 0.01A resolution for precision.
Safety-Designed Jaw: Fully safety-compliant for safe operation in industrial environments.
Long Battery Life: Provides up to 170 hours of continuous measuring time.
Safety Standards: Complies with IEC 61010-1 CAT IV 300V / CAT III 600V for high safety requirements.

Specifications Table

Function	Range	Accuracy
AC Current (ACA)	60.00A / 600.0A / 1000A (Auto-ranging)	±1.5%rdg ±4dgt [45 - 65Hz]; ±2.0%rdg ±5dgt [40Hz - 1kHz]
AC Voltage (ACV)	60.00V / 600.0V (Auto-ranging)	±1.0%rdg ±2dgt [45 - 65Hz] (600V); ±1.5%rdg ±4dgt [40Hz - 1kHz] (60/600V)
DC Voltage (DCV)	60.00V / 600.0V (Auto-ranging)	±1.0%rdg ±3dgt (60V); ±1.2%rdg ±3dgt (600V)
Resistance (Ω)	600.0Ω / 6.000kΩ / 60.00kΩ / 600.0kΩ (Auto-ranging)	±1.0%rdg ±5dgt (600Ω); ±2.0%rdg ±3dgt (6/60/600kΩ)
Continuity Buzzer	600Ω	Buzzer sounds below 90Ω
Conductor Size	Ø33mm max.	—

General Specifications

Feature	Details
Applicable Standards	IEC 61010-1 CAT IV 300V / CAT III 600V, Pollution Degree 2, IEC 61010-031, IEC 61010-2-032, IEC 61010-2-033, IEC 61326-2-2 (EMC), IEC 60529 IP 40, EN 50581 (RoHS)
Power Source	2 × R03 (AAA) (1.5V)
Continuous Measuring Time	Approx. 170 hours (NCV_LED off; auto power save after approx. 10 minutes)
Dimensions	204 mm × 81 mm × 36 mm
Weight	Approx. 220g (including batteries)
Accessories Included	Test leads (7066A), carrying case (9079), 2 × R03 (AAA) batteries, instruction manual

Warranty: 1 Year

Made In: Thailand
