PRO'SKIT SS-989B 2 In 1 SMD Hot Air Rework Station (AC 220~240V) 70W

2X lifetime
Heat fast, 36sec-->300℃
Smart Microprocessor controlled
Auto cooling system
UL certified wire

Accurate temperature control

• Microprocessor temperature controlled
• Temperature calibration function
• Closed circuit sensor design

Certified international safety standard

• Complies with CE and ESD standard, conform to RoHS.
• Comes with AWG 18 (0.823mm²) UL Certified Wires.
• Silicone handpiece cord wire heat-resistant up to 200oC
• Additional ground contact and power cord socket.

High Power, Fast Warm Up & Energy Saving

• Alumina Ceramic Soldering iron heating element features high power, fast warm up.
• Individual function starts save energy, or share function by 2 users at the same time.
• Adjustable temperature and air flow for easy surface or hole mount components QFP, SOP type IC devices rework.
• Interchangeable and applicable to most of branded hot air nozzles and tips


• 3 nozzles included with this rework station.
• Interchangeable hot air nozzles design for different type of surface mount components.
• Also applicable to most of branded heating element and nozzles.

Auto Cool-Off Process to prolong the service lifetime

After power switch is turned off, the auto cool-off process leaves the blower on until the nozzle is cool.

Specification	SS-989E		SS-989B	SS-989H
Power Consumption	700W
Soldering Power	60W
Soldering Iron Temperature Range	200˚C ~ 480˚C (392˚F ~ 896˚F)
Hot Air Temperature Range	Room temperature ~ 480˚C ( 896˚F)
Soldering Iron Heating Element	Alumina Ceramic
Hot Air Heating Element	Metal Heating Core
Pump/Motor Type	Diaphragm Pump
Air Capacity	24L/min (max)
Equipment noise	45dB
Temperature Display	LED
Power Input	AC 110V~120V 60Hz		AC 220V~240V 50Hz	AC220V~240V 50Hz
Standard Plug
Dimensions	255(L)x190(W)x140(H)mm
Weight	4200 g (w/ hot air gun)
Accessories	Hot Air Gun AC110~120Vx1pcs 9SS-900NE-HG		Hot Air Gun AC220~240Vx1pcs 9SS-900NB-HG	Hot Air Gun AC 220~240Vx1pcs 9SS-900NB-HG
	Soldering Iron (AC 24V/60W) 9SS-900N-SI x 1pcs, Soldering Stand x 1pcs, Nozzle 9SS-900-A1 (Ø2.3mm) x 1pcs, Nozzle 9SS-900-A2 (Ø6.4mm) x 1pcs, Nozzle 9SS-900-A3 (Ø8.8mm) x 1pcs
