PRO'SKIT SS-989B 2 In 1 SMD Hot Air Rework Station (AC 220~240V) 70W

Only 3 left
SKU: SS-989B
Regular price RM664.00 MYR
  • Visa
  • Mastercard
  • Touch n Go
  • FPX
  • Boost
  • ShopeePay
  • GrabPay
  • PayPal
  • Union Pay
  • Maybank
  • Google Pay

Pickup available at No.36-1, Jalan Sulaiman 1,

Usually ready in 2-4 days

2X lifetime
Heat fast, 36sec-->300℃
Smart Microprocessor controlled
Auto cooling system
UL certified wire

Accurate temperature control

  • Microprocessor temperature controlled
  • Temperature calibration function
  • Closed circuit sensor design

Certified international safety standard

  • Complies with CE and ESD standard, conform to RoHS.
  • Comes with AWG 18 (0.823mm2) UL Certified Wires.
  • Silicone handpiece cord wire heat-resistant up to 200oC
  • Additional ground contact and power cord socket.

High Power, Fast Warm Up & Energy Saving

  • Alumina Ceramic Soldering iron heating element features high power, fast warm up.
  • Individual function starts save energy, or share function by 2 users at the same time.
  • Adjustable temperature and air flow for easy surface or hole mount components QFP, SOP type IC devices rework.
  • Interchangeable and applicable to most of branded hot air nozzles and tips
  • 3 nozzles included with this rework station.
  • Interchangeable hot air nozzles design for different type of surface mount components.
  • Also applicable to most of branded heating element and nozzles.

Auto Cool-Off Process to prolong the service lifetime

After power switch is turned off, the auto cool-off process leaves the blower on until the nozzle is cool.

Specification SS-989E SS-989B SS-989H
Power Consumption 700W
Soldering Power 60W
Soldering Iron Temperature Range 200˚C ~ 480˚C (392˚F ~ 896˚F)
Hot Air Temperature Range Room temperature ~ 480˚C ( 896˚F)
Soldering Iron Heating Element Alumina Ceramic
Hot Air Heating Element Metal Heating Core
Pump/Motor Type Diaphragm Pump
Air Capacity 24L/min (max)
Equipment noise 45dB
Temperature Display LED
Power Input

AC 110V~120V

60Hz

AC 220V~240V

50Hz

AC220V~240V

50Hz
Standard Plug
Dimensions 255(L)x190(W)x140(H)mm
Weight 4200 g (w/ hot air gun)
Accessories

Hot Air Gun
AC110~120Vx1pcs

9SS-900NE-HG

Hot Air Gun
AC220~240Vx1pcs

9SS-900NB-HG

Hot Air Gun
AC 220~240Vx1pcs

9SS-900NB-HG

Soldering Iron (AC 24V/60W) 9SS-900N-SI x 1pcs, Soldering Stand x 1pcs, Nozzle 9SS-900-A1 (Ø2.3mm) x 1pcs, Nozzle 9SS-900-A2 (Ø6.4mm) x 1pcs, Nozzle 9SS-900-A3 (Ø8.8mm) x 1pcs
