Fluke 59 MAX Infrared Thermometer -30°C to 350°C, 8:1 D:S with Hi/Lo Alarms
Couldn't load pickup availability
The Fluke 59 MAX Infrared Thermometer is a compact, reliable non-contact IR thermometer (temperature gun) for industrial, commercial and HVAC work. It reads surface temperatures from -30°C to 350°C with an 8:1 distance-to-spot ratio, so you can check hot, moving or hard-to-reach surfaces from a safe distance. Its ergonomic, toolbox-friendly design makes it ideal for fieldwork, troubleshooting and preventive maintenance.
59 MAX or 59 MAX+? The 59 MAX covers -30°C to 350°C. If you need readings up to 500°C with a 10:1 spot ratio, see the Fluke 59 MAX+ Infrared Thermometer.
Key Features & Benefits
- Laser targeting – single laser helps you aim consistently at the same surface point
- Large backlit LCD – easy to read in plant rooms and electrical panels
- Compact and lightweight – 220g, fits easily into a toolbox
- IP40 housing – protection against dust and solid particles; 1m drop tested
- 8:1 distance-to-spot ratio – measure from a safe distance
- MIN/MAX/AVG/DIF display – minimum, maximum, average or difference between readings
- Hi/Lo alarms – quickly identify readings outside set limits
- Single AA battery – up to 12 hours with laser and backlight on
Technical Specifications
| Specification | Value |
|---|---|
| Temperature range | -30°C to 350°C (-22°F to 662°F) |
| Accuracy (23°C ±2°C ambient) | ≥0°C: ±2.0°C or ±2.0% of reading, whichever is greater -10°C to <0°C: ±2.0°C <-10°C: ±3.0°C |
| Repeatability | ±1.0% of reading or ±1.0°C, whichever is greater |
| Display resolution | 0.1°C (0.2°F) |
| Distance-to-spot ratio | 8:1 (calculated at 90% energy) |
| Response time | <500ms (95% of reading) |
| Spectral response | 8 to 14µm |
| Emissivity | 0.10 to 1.00 |
| Power | 1 x AA IEC LR06 battery |
| Battery life | 12 hours with laser and backlight on |
| Operating temperature | 0°C to 50°C (32°F to 122°F) |
| Storage temperature | -20°C to 60°C (-4°F to 140°F), without battery |
| Operating humidity | 10% to 90% RH non-condensing at 30°C (86°F) |
| Altitude | Operating 2,000m; storage 12,000m |
| Drop test | 1m |
| Vibration and shock | IEC 68-2-6 2.5g, 10 to 200Hz; IEC 68-2-27, 50g, 11ms |
| Ingress protection | IP40 per IEC 60529 |
| Dimensions | 156 x 80 x 50mm (6.14 x 3.15 x 2 in) |
| Weight | 220g (7.76 oz) |
| Country of origin | Made in China |
Safety & Compliance
- Safety: EN/IEC 61010-1
- Laser safety: FDA and EN 60825-1 Class II
- EMC: IEC 61326-1, EN 61326-2
What's in the Box
- Fluke 59 MAX Infrared Thermometer
- 1 x AA battery
- Quick Reference Guide
Applications
- HVAC diagnostics and ductwork temperature testing
- Electrical maintenance and panel hot-spot detection
- Industrial troubleshooting and preventive maintenance
- Mechanical inspection and bearing temperature checks
Fluke infrared thermometer comparison
| Specification | Fluke 59 MAX (this model) | Fluke 59 MAX+ | Fluke 62 MAX | Fluke 62 MAX+ | Fluke 561 | Fluke 572-2 |
|---|---|---|---|---|---|---|
| IR range | -30°C to 350°C | -30°C to 500°C | -30°C to 500°C | -30°C to 650°C | -40°C to 550°C | -30°C to 900°C |
| Accuracy (≥0°C) | ±2.0°C or ±2.0% | ±1.5°C or ±1.5% | ±1.5°C or ±1.5% | ±1.0°C or ±1.0% | ±1°C or ±1% | ±1°C or ±1% |
| Distance-to-spot | 8:1 | 10:1 | 10:1 | 12:1 | 12:1 | 60:1 |
| Laser | Single | Single | Single | Dual | Single | Offset dual |
| K-type contact input | No | No | No | No | Yes | Yes (-270°C to 1372°C) |
| Rugged rating | IP40, 1m drop | IP40, 1m drop | IP54, 3m drop | IP54, 3m drop | - | - |
| Battery life (laser + backlight on) | 12h (1 x AA) | 12h (1 x AA) | 10h (1 x AA) | 8h (1 x AA) | 12h (2 x AA) | 8h (2 x AA) |
| Best for | Basic spot checks | Wider range at low cost | Rugged field use | Higher range, dual laser | HVAC IR + pipe probe | High-temperature industrial work, logging |
| Warranty period | 1 Year Warranty |
|---|---|
| Coverage | Free from defects in material and workmanship for 1 year from the date of purchase, including accessories supplied with the product, such as test leads and probes. |
| Not covered | Fuses, disposable batteries and manuals; damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling. For Fluke Networks products, parts and accessories (including rechargeable batteries and cables) are covered for 90 days. |
| Warranty void if | The product has been used outside its specifications, altered, or repaired by a party not authorised by Fluke. |
Contact Techno Tools with your proof of purchase. The warranty applies to the original purchaser only.
