KYORITSU 1020R Digital Multimeter ≤1000V (KEW 1020R)

Name: KYORITSU 1020R Digital Multimeter ≤1000V (KEW 1020R)
Brand: KYORITSU
SKU: KE 1020R
Price: 547.00 MYR
Availability: InStock

In stock - 4 items available

SKU: KE 1020R

RM547.00 MYR

-18% ~~RM670.00 MYR~~ RM547.00 MYR

Helpful Documents

Product Brochure Download
Product Datasheet / User manual Download

Pickup available at No.36-1, Jalan Sulaiman 1,

Usually ready in 2-4 days

Got questions?

Feel free to WhatsApp us

Ask an expert

Chat Email +6012-9725395

KEW 1020R Digital Multimeter

The KEW 1020R Digital Multimeter is your reliable partner for precise electrical measurements. Built to comply with CAT IV 300V / CAT III 600V / CAT II 1000V safety standards, it ensures maximum safety and performance in demanding environments. Its advanced True RMS technology delivers accurate readings even for non-linear waveforms caused by modern devices like LED lighting, motor inverters, and more.

Key Features:

Wide Measurement Ranges: Measure DC/AC voltage up to 1000V, resistance up to 40MΩ, and capacitance up to 1000μF.
True RMS Accuracy: Provides precise readings for distorted or non-sinusoidal waveforms.
Rugged Design: Designed to endure tough conditions while meeting IEC 61010-1 safety standards.
Intuitive Interface: A large 6000-count backlit LCD display ensures visibility in all conditions.
Multifunctional Features: Includes MIN/MAX recording, data hold, continuity buzzer, and sleep mode for efficiency.
Clamp Sensor Ready: Compatible with optional AC/DC clamp sensors for extended functionality.
Long-Lasting Power: Energy-efficient design with approximately 200 hours of battery life.

Specifications Table

Function	Range	Accuracy
AC Voltage (ACV)	6.000V to 1000V (Auto Range)	±1.0%rdg ±3dgt (40-500Hz, ≤600V); ±1.3%rdg ±3dgt (>600V)
DC Voltage (DCV)	6.000V to 1000V (Auto Range)	±0.5%rdg ±3dgt (≤600V); ±0.8%rdg ±3dgt (>600V)
Resistance (Ω)	600.0Ω to 40.00MΩ	±0.5%rdg ±2-4dgt
Capacitance (F)	60.00nF to 1000μF	±2.0%rdg ±5dgt (60/600nF); ±5.0%rdg ±5dgt (6μF-1000μF)
Frequency (Hz)	99.99Hz to 99.99kHz	±0.1%rdg ±3dgt
Diode Test	Up to 2.000V	±5%rdg ±5dgt
Duty Cycle (%)	10.0% - 90.0%	±1.0%rdg ±3dgt (50/60Hz)
AC/DC Clamp Mode	60.00A to 200.0A	±2.0%rdg ±3dgt

General Specifications

Feature	Details
Display	6000-count LCD with backlight
Safety Standards	IEC 61010-1, CAT IV 300V / CAT III 600V / CAT II 1000V
Power Supply	2 × 1.5V AAA batteries (R03/LR03)
Dimensions	155 mm × 75 mm × 40 mm
Weight	Approx. 250g (with batteries and holder)
Accessories Included	Test leads (M-7066A), Instruction manual, 2 × AAA batteries, Wing-type holder
Optional Accessories	Alligator clips, AC/DC clamp sensor, magnet hanger strap
Operating Conditions	0°C to 40°C, ≤80% RH (no condensation)
Storage Conditions	-20°C to 60°C, ≤80% RH (no condensation)
IP Rating	IP40 (dust protection)

Warranty: 1 Year

Made In: Thailand
