KEW MATE 2012RA Digital Multimeter with AC/DC Clamp Sensor

The KEW MATE 2012RA Digital Multimeter is a versatile and compact multimeter equipped with an OPEN CLAMP SENSOR that can measure both AC and DC currents up to 120A. Designed for heavy-duty use, it features enhanced cable protection, a test probe that can be fixed to the holster, and a slim jaw design that allows it to clamp wires even in tight spaces. Ideal for professionals on the move, this pocket-sized multimeter offers exceptional reliability and performance.

Video:

Key Features:

  • High Current Measurement: Measures up to 120A for both AC and DC currents with the OPEN CLAMP SENSOR.
  • Robust Cable Protection: Improved cable strength and protection ensure durability during use.
  • Compact and Portable: Small, pocket-sized design for easy portability and convenient storage.
  • Test Probe Holster: Test probe can be securely fixed to the holster for safe and convenient handling.
  • Safety Features: Includes a test lead cap to prevent short circuit accidents.
  • Slim Clamp Jaws: The open jaws are designed to fit into tight spaces, making it easy to clamp wires in cramped environments.

Specifications Table

Function Range Accuracy
DC Voltage (DCV) 600.0mV / 6.000V / 60.00V / 600.0V ±1.0%rdg ±3dgt
AC Voltage (ACV) 6.000V / 60.00V / 600.0V ±1.5%rdg ±5dgt (45 - 400Hz)
DC Current (DCA) 60.00A / 120.0A ±2.0%rdg ±8dgt (60A); ±2.0%rdg ±5dgt (120A)
AC Current (ACA) 60.00A / 120.0A ±2.0%rdg ±5dgt (45 - 65Hz)
Resistance (Ω) 600.0Ω / 6.000kΩ / 60.00kΩ / 600.0kΩ / 6.000MΩ / 60.00MΩ ±1.0%rdg ±5dgt (600Ω - 600kΩ); ±2.0%rdg ±5dgt (6MΩ); ±3.0%rdg ±5dgt (60MΩ)
Continuity Buzzer Buzzer sounds below 35 ±25Ω —
Diode Test 2.000V ±3.0%rdg ±5dgt (Open-loop voltage: approx. 2.7V)
Capacitance (F) 400.0nF / 4.000µF / 40.00µF ±2.5%rdg ±10dgt
Frequency AC A: 99.99Hz / 400Hz; AC V: 99.99Hz / 999.9Hz / 9.999kHz / 99.99kHz / 300.0kHz ±0.2%rdg ±2dgt (100Hz); ±0.1%rdg ±1dgt (1000Hz / 10kHz / 300kHz)
Conductor Size Ø12mm max. —

General Specifications

Feature Details
Applicable Standards IEC 61010-1 CAT III 300V, CAT II 600V, Pollution Degree 2, IEC 61010-031, IEC 61010-2-032, IEC 61326-1, EN 50581 (RoHS)
Power Source 2 × R03 (AAA) (1.5V)
Dimensions 128 mm × 92 mm × 27 mm
Weight Approx. 220g (including batteries)
Accessories Included Test leads, 2 × R03 (AAA) batteries, instruction manual
Optional Accessories Soft carrying case (9107)
Warranty: 1 Year
Made In: Thailand
