KYORITSU 1110 Analog Multimeter ≤600V | KEW 1110

Name: KYORITSU 1110 Analog Multimeter ≤600V | KEW 1110
Brand: KYORITSU
SKU: KE 1110
Price: 541.00 MYR
Availability: InStock

In stock - 6 items available

SKU: KE 1110

RM541.00 MYR

-20% ~~RM680.00 MYR~~ RM541.00 MYR

Helpful Documents

Product Datasheet / User manual Download

Pickup available at No.36-1, Jalan Sulaiman 1,

Usually ready in 2-4 days

Got questions?

Feel free to WhatsApp us

Ask an expert

Chat Email +6012-9725395

Model 1110 Analog Multimeter

The Model 1110 Analog Multimeter is a high-sensitivity tool designed for durability and reliability in various electrical testing applications. With a DC 20kΩ/V sensitivity and a robust design, it withstands a 1-meter drop and is equipped with advanced features like continuity buzzer, battery check, and LED check functionality. Its skeleton-type case with a carrying handle ensures convenience and protection during transport.

Key Features:

High Sensitivity: Offers DC sensitivity of 20kΩ/V for precise measurements.
Durable Design: Withstands a 1-meter drop with its rugged, heavy-duty construction.
AC Voltage Measurement: Measures line voltage up to AC 600V, protected by a ceramic fuse against accidental overload.
Versatile Functions: Includes continuity buzzer, battery check, and LED check functions.
Convenient Carrying: Comes with a skeleton-type case and handle for portability and protection.

Specifications Table

Function	Range	Accuracy
DC Voltage (DCV)	0.3V (16.7kΩ/V); 3/12/30/120/300/600V (20kΩ/V)	±3% of FS
AC Voltage (ACV)	12V (9kΩ/V); 30/120/300/600V (9kΩ/V)	±4% of FS (12V); ±3% of FS (30-600V)
DC Current (DCA)	60µA / 30 / 300mA	±3% of FS
Resistance (Ω)	3 / 30 / 300kΩ	±3% of scale length
Continuity Buzzer	Sounds below 100Ω	—
Battery Test	1.5V (0.7 - 2V, 10Ω load)	±3% of FS
LED Check	Approx. 10mA at 0Ω (at 3V of battery voltage)	—

General Specifications

Feature	Details
Applicable Standards	IEC 61010-1 CAT III 300V / CAT II 600V, IEC 61010-2-031
Power Source	2 × R6 (AA) (1.5V)
Dimensions	140 mm × 94 mm × 39 mm
Weight	Approx. 280g
Accessories Included	Test leads (7066A), 0.5A/600V fuses (1 installed, 1 spare), carrying case (9103), R6 (AA) batteries × 2, instruction manual

Warranty: 1 Year

Made In: Thailand
